New Product - PBS Koilmatic







New Product - Total Cut & Bend*
Download a Printable PDF

Dual Sided Crimping Unit for coil diameters from 6 mm to 50 mm
The TCB - Total Cut & Bend with its patented design can cut and crimp the full range of plastic spiral diameters from 6 mm up to 50 mm - with the same crimping heads!

(U.S. Patents # 7,731,468 & # 7,828,503)

Features

• No tools required for size changeovers.
• Accommodates coil diameters from 6 mm to 50 mm without the need to change crimp heads.
• Min/Max binding edge 5.5" - 17" (14 cm - 43 cm)
• Easy to follow decals guide the operator through setup.
• Removable off-cut tray makes accumulation and disposal of off-cuts neat and tidy.
• Available with electric or pneumatic actuation.
• Foot pedal operated.

Benefits

• Simple dial adjustments enable you to setup, cut and crimp coil diameters from 6 mm to 50 mm with the same crimping heads!
• Longer crimp achieved as the coil diameter increases reducing the risk of coil unwinding from the larger punch holes.
• Large top surface doubles as useable workspace.
• Easily integrated with most coil insertion equipment.

Technical Specs

• Electric version - 110 V or 220 V Single phase
• Pneumatic version - Compressed air requirements: 80 psi @ 1 cfm
• CE Compliant
• Dimensions 28"W x 16"D x 12"H (71 cm x 41 cm x 30.5 cm)
• Weight - 40 lbs. (18 kgs)

New Product - Industrial Roller Inserter
Download a Printable PDF

The power of two spinning rollers for quick and efficient coil insertion
The PBS Industrial Roller Inserter offers dual roller insertion within a rugged steel frame. A durable design that is built to last!

Features
Both rollers spin providing more force/ less friction to drive the coil through the punch holes. You'll notice a real difference when binding thicker books.

Productivity

• As high as 350 books/hour

Coil Capabilities

• Accommodates coil diameters from 6 mm up to 32 mm

Min/Max Binding Edge

• No limits

Rollers spin continuously

Benefits

• Small and compact, it can fit on any desk or countertop
• The front alignment channel curves the book to follow the curve of the coil allowing for easier coil insertion.
• The front book support ensures the book and coil are positioned against the rollers.
• Large top surface doubles as useable workspace.

Technical Specs

• 110 V Single phase (220 V/Single also available)
• CE Compliant
• Dimensions 20"W x 10"D x 7"H (51 cm x 25.4 cm x 18 cm)
• Weight - 15 lbs. (7 kgs)
